Name: BZC8050 Series Aluminium Alloy Control Station IP65 Protection ATEX IECEx Certified
Brand: Warom
Price: 1 USD

Brand Name : Warom

Model Number : BZC8050

Certification : IECEx; ATEX; CU-TR

Place of Origin : China

Payment Terms : T/T

Packaging Details : carton packing/wooden box package

Explosion protection : CENELEC,IEC,NEC

Can be used in : Zone1,2,21,22,Class I,Zone 1,2.Class I,Division 2,Groups A,B,C,D

Contact Now

Product Introduction

BZC8050 Series Aluminium Alloy Control Station IP65 Protection ATEX IECEx Certified

Specification

Global (IECEx)	IECEx CQM 24.0057X
Gas and dust	Ex db eb mb IIC T6/T5 Gb Ex db eb IIC T80℃ Db
Europe (ATEX)	TUY CY 25 ATEX 0207269X
Gas and dust	II 2 G Ex db eb mb IIC T6/T5 Gb II 2 G Ex db eb IIC T6/T5 Gb II 2 D Ex tb IIIC T80℃ Db
Gas and dust
Certificates	IECEx; ATEX; CU-TR
Conformity to standards	EN; IEC
Degree of protection	IP66
Ambient temperature	-60℃(-40℃)~+55℃(+40℃)

Data

Material	Copper-free Aluminium Alloy, powder coated surface
Dimensions	As per design
Enclosure colour	Window grey (RAL7040)
Exposed fastener	Stainless steel
Rated voltage	Max. 500V/440V AC Max.220V DC
Rated current	16A,10A
Internal&external earthing	I, II, III: M4/M4; IV, V, VI,VII: M6/M6
Cable entries	M□ x 1.5 plug
Cable gland (optional)	DQM-I (Ex e)
Mounting	Surface type

Download

BZC8050 Series Control Stations (Aluminium Alloy)

Global (IECEx): IECEx CQM 24.0057X
